Lancer Soda Fountain Dispenser FS30
Lancer
$ 8,480.00 $ 19,026.01
- Lancer Flavor Select - FS30
-
16 Brands for over 100 Flavor Possibilities
- Cold carbonation for consistently better drink quality
-
Add up to 12 bonus flavors to create an exceptional drink experience
-
“Lite Touch” brand light show draws attention to your fountain section!
-
Self-contained with multiple ice fill options
-
Fits in current 30" IBD footprint “Air Mix” nozzles blend syrup and water in midair for consistent drink delivery
-
Illuminated easily interchangeable merchandiser
-
Large capacity removable drip tray and cup rest
-
Cubelet ice capable dispense is available-specifications on request
- Lancer Part # 85-14816-12
-
FOB Sacramento, CA (95826)
Product Specifications
| HEIGHT | 40.25" (899 mm) |
| WIDTH | 30" (762 mm) |
| DEPTH | 30.5" (775 mm) |
| Space required | Width: 32” (812.8 mm) Depth: 31.5” (800.1 mm) Top: 6 in (152 mm) Access to floor drain suggested |
| Electrical | 115V/60Hz, 7AMPs |
| Weight | Without ice: 320 lbs (145 kg) |
| With ice: 610 lbs (281 kg) | |
| Shipping: 356 lbs (161 kg) | |
| Ice | Capacity: 290 lbs (132 kg) |
| Dispensable: 215 lbs (98 kg) | |
| Fittings | Soda inlets: 3/8'' (9.5 mm ) barb Syrup inlets: 3/8’’ (9.5 mm ) barb |
| Water | Filtered water 50 psi min |
| Valves # | 4 |
| Valve type | Lancer Flow Control Valves (LFCV) |
| Key lock switch | Yes |
| Cold Carbonation | Yes |
| Beverage Combinations | over 100 |
| Beverage Brands | 16 |
| Certifications | ETL, ISO 9001, ISO 14001, NSF model FS30 |
| Options | Lancer “Lite Touch” user interface panels, ADA kit, legs: 4 in (102 mm) |
